Additional information
| Valve Size | 1 1/2 in |
|---|---|
| Electric Voltage | 12 VDC, 24 VAC, 24 VDC |
| REPLACEMENT OR OBSOLETE ITEM | REPLACEMENT |
| CROSS REFERENCE ITEM | 2PC SS ELECTRIC, EHS27AJE25H |
| Series | E2S |
| Operation Type | Actuator |
| Actuator Type | DE155 |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI (D) | 300 psi |
| Valve CWP | 1000 psi |
| Porting Style | Full |
| Port Opening Size | 1 1/2 |
| Temperature Range - Media | -4 to 392ºF |
| Temperature Range - Ambient | -40 to 150ºF |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Valve Body Material | Stainless Steel |
| Valve Construction | Stainless Steel |
| Stem Seal Type | PTFE/Viton® |
| Body Finish | Stainless Steel |
| Ball Material | 316 Stainless Steel |
| Seat Material | RTFE/PTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | 316 Stainless Steel |
| A Dimensions | 4.72 in |
| C Dimensions | 1.50 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
