Additional information
| Valve Type | Ball |
|---|---|
| Porting Style | Full |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Valve Body Material | Stainless Steel |
| Valve Construction | Stainless Steel |
| Stem Seal Type | PTFE/Viton® |
| Body Finish | Stainless Steel |
| Ball Material | 316 Stainless Steel |
| Stem Material | 316 Stainless Steel |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Seat Material | Delrin® |
| Seal Type | PTFE |
| Temperature Range - Media | -20° / 185°F |
| Operating PSI (D) | 3000 PSI |
| Valve Size | 1 1/2 in |
| Electric Voltage | 120 VAC |
| Temperature Range - Ambient | -40 to 150 ºF |
| Actuator Type | MA7 |
