EHH27ATJE3S, 2PC BR ELEC BV 24-240 VAC/VDC

EHH27ATJE3S, 2PC BR ELEC BV 24-240 VAC/VDC

SKU: EHH27ATJE3S Category:
Printable Page
Email This Page
Save To Favorites
EHH27ATJE3S Spec Sheet
EHH Series Brass JE Electric (Sub 400)

Additional information

Valve Construction

Brass
Seat Material

PTFE/Viton®
Valve Size

1 1/2 in
Electric Voltage

24-240 VAC 24-135 VDC

Description

The DynaMatic EHH Series of electrically actuated brass valves offers an excellent option for automated applications requiring durable yet economical brass. These automated valves fit a wide range of applications, and all models are pre-sized for clean water, air, or light oil applications. Please contact customer service for recommendations and actuator sizing when dirty or severe service applications are needed. The EHH Series uses our DE, MA, and JE Series electrical actuators. The EHH Series valves are available from 24 to 240 VAC/VDC.

Features Include:

  • NPT Female Threaded Ends
  • Forged Brass Construction
  • RTFE Seats, PTFE/Viton Stem Seals
  • Bottom Loaded Stem
  • ISO 5211 Direct Mounting
  • Full Port
