Additional information
| Actuator Model | AJE3S |
|---|---|
| Actuator Type | ON/OFF |
| Body Style | 3-Way Diverter |
| Operating PSI(D) | 400cwp – 100wsp |
| Porting Style | Standard L |
| Seal Type | Viton |
| Seat Material | PTFE |
| Series | EYHG |
| Temperature Range - Ambient | -4° / 158°F |
| Temperature Range - Media | -4 to 210 °F |
| Thread Type | FNPT |
| Valve Body Material | Brass |
| Valve Size | 1" |
| Valve Type | Ball |
| Voltage | 24-240 VAC/24-135 VDC |
| WEIGHT LBS | 6.84 |
