Additional information
| A Dimensions | 4.33 in |
|---|---|
| Actuator Model | DE304 |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Ball Material | 316 Stainless Steel |
| Body Finish | Stainless Steel |
| Body Style | 3 Piece |
| C Dimensions | 0.98 in |
| CROSS REFERENCE ITEM | EVS26AJE25H |
| Number of Ports | 2 |
| Operating PSI(D) | 300 psi |
| Operator | Actuator |
| Port Opening Size | 1 1/4 |
| Porting Style | Full |
| REPLACEMENT OR OBSOLETE ITEM | REPLACEMENT |
| Seal Type | PTFE/Viton® |
| Seat Material | RTFE |
| Series | E3S |
| Stem Material | 316 Stainless Steel |
| Stem Seal Type | PTFE/Viton® |
| Temperature Range - Ambient | -40 to 150 °F |
| Temperature Range - Media | -4 to 392 °F |
| Thread Type | FNPT |
| Valve Body Material | Stainless Steel |
| Valve CWP | 1000 psi |
| Valve Construction | Stainless Steel |
| Valve Size | 1 1/4 in |
| Valve Type | Ball |
| Voltage | 12 VDC, 24 VAC, 24 VDC |
