Additional information
| Actuator Model | DE156H |
|---|---|
| Actuator Type | Electric |
| Addl Voltage | 24 VDC |
| Addl Voltage 1 | 12 VDC |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Ball Material | 316 Stainless Steel |
| Body Finish | Bronze |
| Body Length | 2.68 in |
| Body Style | 3 Piece |
| C Dimensions | 0.44 in |
| D Dimensions | 6.77 in |
| Electric Voltage | 12 VDC, 24 VAC, 24 VDC |
| F Dimensions | 5.66 in |
| G Dimensions | 5.18 in |
| Number of Ports | 2 |
| Operating PSI(D) | 300 psi |
| Operator | Actuator |
| Port Opening Size | 4-Jan |
| Porting Style | Full |
| Seal Type | PTFE/Viton® |
| Seat Material | PTFE |
| Series | EVA |
| Stem Material | Stainless Steel |
| Stem Seal Type | PTFE/Viton® |
| Temperature Range - Ambient | -40 to 150 °F |
| Temperature Range - Media | -20°F to 400°F |
| Thread Type | FNPT |
| Valve Body Material | Bronze |
| Valve CWP | 600 psi |
| Valve Construction | Bronze |
| Valve Size | 1/4 in |
| Valve Type | Ball |
| Voltage | 24 VAC |
| Weight | 5.32 lb |
