Additional information
| SIZE | 3/4" |
|---|---|
| Pressure PSI | 400cwp – 100wsp |
| A | 3.19 |
| B | 1.53 |
| C | 0.59 |
| D | 1.6 |
| E | 0.87 |
| F | 1.29 |
| G | 7.94 |
| H | 4.34 |
| J | 7.13 |
| K | 6.65 |
| Actuator Part Number | AJE2S00F |
| Ambient Temp | -4° / 158°F |
| WT. LBS. | 5.47 |
| Electric Voltage | 24-240 VAC/24-135 VDC |
| Actuator Option | Fail Close |
| Valve Type | Ball |
| Thread Type | FNPT |
| Seat Material | PTFE |
| Seal Type | Viton |
| Valve Body | Brass |
| Porting | Standard |
| Temperature Range - Media | -4 to 200 °F |
