Additional information
| Voltage | 12 VDC |
|---|---|
| Phase | 1 |
| Actuator Type | ON/OFF |
| Torque Output (in/lbs) | 795 |
| Cycle Time (sec) | 15 |
| Mount Type | ISO F07 |
| ENCLOSURE | NEMA 4 / NEMA 4X Weatherproof/Corrosion Resistant Housing |
| Height | 10.04 in |
| Width | 7.87 in |
| Length | 13.00 in |
| Weight | 20.00 lb |
| Temperature Range - Ambient | 10 to 140 °F |
| Type | Electric, Locking Gearing, Permanent Split Capacitor, Quarter-Turn, Reversing |
| Material | Die-Cast Aluminum, Epoxy Coating |
| Standard MA Series Features | Long Life Reserving MotorsThermal Overload ProtectionISO 5211 Shaft and Mounting Dimensions (F06 – F16 Configurations)Can be Mounted up to 90 degrees from vertical, Quarter Turn Control with Remote Indication of End of TravelNon-Clutch, Side-Mounted Hand Wheel for Manual OverrideTwo (2) 1/2" NPT Conduit EntriesSelf-Locking |
| Optional MA Series Features | 12 VAC, 220 VAC (1 Phase), 220 VAC (3 Phase) and Low Voltage 12 VDC, 24 VAC. Auxiliary Limit Switches to indicate valve positions remotely or to control other pieces of equipment, 24 VDC, Multiple voltages available including 120 VAC |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Ball Valves, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Dampers, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, Gate Valves, General Chemical Applications, Globe Valves, HVAC controls, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Plug Valve, Quarter-turn Valves, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Note | Ball Valve Actuator, Butterfly Actuator, Damper Applications, Electric, Extra Limit Switches, Hand-Wheel Manual Override, Permanent Split Capacitor, Plug Valve Actuator, Quarter-Turn, Reversing, Rotary |
