Additional information
| Actuator Type | HP052DA |
|---|---|
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Ball Material | 316 Stainless Steel |
| Body Finish | Stainless Steel |
| Body Style | 2 Piece |
| CROSS REFERENCE | PAS22ARUDA020 |
| Number of Ports | 2 |
| Operating PSI(D) | 3000 PSI |
| Operator | Actuator |
| Pneumatic Actuator Type | Double Acting |
| Port Opening | 3/8 |
| Port Style | Full |
| REPLACEMENT OR OBSOLETE | OBSOLETE |
| Seal Type | PTFE |
| Seat Material | Delrin® |
| Series | PAS |
| Temperature Range - Standard Temp Actuator | -4 to 176 °F |
| Temperature Range - Low Temp Actuator | -20° / 176°F |
| Temperature Range - High Temp Actuator | N/A |
| Valve Size | 3/8 in |
