Additional information
| Actuator Features | -4 to 176 deg F (Low Temp and High Temp also available), 4X) to provide local and remote indication of valve position (2 SPDT switches)Life-time lubricated, high cycling, Quarter-Turn, rack and pinion |
|---|---|
| Actuator Type | UP020DA |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Ball Material | Nickel Plated Brass |
| Body Finish | Brass |
| Body Style | 3-Way |
| Number of Ports | 3 |
| Operating PSI(D) | 300 psi |
| Operator | Actuator |
| Pneumatic Actuator Type | Double Acting |
| Port Opening Size | 1 1/2 |
| Porting Style | L Port |
| REPLACEMENT OR OBSOLETE ITEM | REPLACEMENT |
| Seal Type | PTFE/Viton® |
| Seat Material | PTFE/Viton® |
| Series | PYHG |
| Stem Material | Nickel Plated Brass |
| Stem Seal Type | Viton® |
| Temperature Range - Standard Temp Actuator | -4 to 176 °F |
| Temperature Range - Low Temp Actuator | N/A |
| Temperature Range - High Temp Actuator | 5 to 302 °F |
| Thread Type | FNPT |
| Valve Body Material | Brass |
| Valve CWP | 400 psi |
| Valve Construction | Brass |
| Valve Features | 100 WSP Sized for 300 psid media., Standard PortBrass Body with Ni-Chrome Plated BallPTFE Seats, Viton® O-Ring Stem SealBottom Loaded StemAvailable in 1/4" – 3" FNPT Ends400 PSI WOG |
| Valve Size | 1 1/2 in |
