Additional information
| SIZE | 3" |
|---|---|
| Pressure PSI | 400cwp – 100wsp |
| A | 7.08 |
| B | 4.45 |
| C | 1.95 |
| D | 3.54 |
| E | 2.2 |
| F | 3.35 |
| G | 11.07 |
| H | 4.34 |
| J | 7.13 |
| K | 7.72 |
| Actuator Part Number | AJE7V00F |
| Ambient Temp | -4° / 158°F |
| WT. LBS. | 26.15 |
| Electric Voltage | 12VAC/VDC |
| Actuator Option | Fail Close |
| Valve Type | Ball |
| Thread Type | FNPT |
| Seat Material | PTFE |
| Seal Type | Viton |
| Valve Body | Brass |
| Porting | Standard |
| Temperature Range - Media | -4 to 200 °F |
