Additional information
| Valve Size | 3 in |
|---|---|
| Pneumatic Actuator Type | Spring Return – Fail Closed |
| Pneumatic Actuator Accessories | Pilot Solenoid 24 VDC |
| REPLACEMENT OR OBSOLETE ITEM | OBSOLETE |
| CROSS REFERENCE ITEM | P5C6AEJSR12510A3 |
| Series | PHC FL |
| Operator | Actuator |
| Actuator Type | Pneumatic |
| Actuator Part Number | AP295SR4 |
| Valve Type | Ball |
| Thread Type | 150 ANSI Flange |
| Operating PSI (D) | 285 psi |
| Valve CWP | 285 psi |
| Porting Style | Full |
| Port Opening Size | 3 |
| Temperature Range - Media | -20 to 450 ºF |
| Temperature Range - Ambient | -10 to 195 ºF |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Value Body Material | Carbon Steel |
| Valve Cold Working Pressure (PSI) | ANSI 150 |
| Valve Construction | Carbon Steel |
| Stem Seal Type | PTFE/Viton® |
| Body Finish | Carbon Steel |
| Ball Material | 316 Stainless Steel |
| Seat Material | RTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | 316 Stainless Steel |
| Body Length | 8.00 in |
| B Dimensions | 2.99 in |
| C Dimensions | 7.50 in |
| D Dimensions | 4.39 in |
| E Dimensions | 6.30 in |
| F Dimensions | 11.48 in |
| G Dimensions | 11.75 in |
| H Dimensions | 5.39 in |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
