Additional information
| Valve Size | 1 1/4 in |
|---|---|
| Pneumatic Actuator Type | Double Acting |
| Pneumatic Actuator Accessories | Pilot Solenoid 115 VAC |
| REPLACEMENT OR OBSOLETE ITEM | OBSOLETE |
| CROSS REFERENCE ITEM | PHH26ATDA052A |
| Series | PHG |
| Operator | Actuator |
| Actuator Part Number | AP20DA |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI(D) | 300 psi |
| Valve CWP | 600 psi |
| Porting Style | Full |
| Port Opening Size | 1 1/4 |
| Temperature Range - Media | -20 to 370 ºF |
| Temperature Range - Ambient | -10 to 195 ºF |
| Weight | 7.25 lb |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Body Material | Lead-Free Brass |
| Valve Construction | Lead-Free Brass |
| Stem Seal Type | Viton® |
| Body Finish | Lead-Free Brass |
| Ball Material | Chrome Plated Lead-Free Brass |
| Seat Material | RTFE |
| Seal Type | Viton®/RTFE |
| Stem Material | Nickel Plated Lead-Free Brass |
| Body Length | 4.09 in |
| B Dimensions | 2.56 in |
| Body Inner Diameter | 1.26 in |
| D Dimensions | 2.18 in |
| E Dimensions | 5.53 in |
| F Dimensions | 5.24 in |
| G Dimensions | 2.70 in |
| H Dimensions | 3.35 in |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Valve Features | Full PortNSF/ANSI 372 "Lead Free" Forged Brass BodyRTFE Seats, Viton® Stem SealsBottom Loaded StemAvailable in 1/2" – 1 1/2" FNPT Ends600 PSI WOG Assembly sized for 300 psid media |
| Actuator Features | -4 to 176 deg F (Low Temp and High Temp also available), 4X) to provide local and remote indication of valve position (2 SPDT switches)Life-time lubricated, high cycling, Quarter-Turn, rack and pinion |
