Additional information
| Valve Size | 1/2 in |
|---|---|
| Pneumatic Actuator Type | Spring Return – Fail Closed |
| Pneumatic Actuator Accessories | Pilot Solenoid 115 VAC |
| REPLACEMENT OR OBSOLETE ITEM | REPLACEMENT |
| CROSS REFERENCE ITEM | PHH23ATS012A |
| Series | PHH |
| Operator | Actuator |
| Actuator Type | HP052SR10 |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI(D) | 300 psi |
| Valve CWP | 600 psi |
| Porting Style | Full |
| Port Opening Size | 2-Jan |
| Temperature Range - Media | -20 to 370 ºF |
| Temperature Range - Ambient | -4 to 176 ºF |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Valve Body Material | Brass |
| Valve Construction | Brass |
| Stem Seal Type | Viton |
| Body Finish | Brass |
| Ball Material | Chrome Plated Brass |
| Seat Material | Viton |
| Seal Type | Viton |
| Stem Material | Nickel Plated Brass |
| A Dimensions | 2.60 in |
| C Dimensions | 0.59 in |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Valve Features | Full PortCW617N Forged Brass BodyRTFE Seats, Viton® Stem SealsBottom Loaded StemAvailable in 1/2" – 4" FNPT Ends600 PSI WOG Assembly sized for 300 psid media. |
| Actuator Features | -4 to 176 deg F (Low Temp and High Temp also available), 4X) to provide local and remote indication of valve position (2 SPDT switches)Life-time lubricated, high cycling, Quarter-Turn, rack and pinion |
