Additional information
| Valve Size | 2 in |
|---|---|
| Pneumatic Actuator Type | Spring Return – Fail Closed |
| Pneumatic Actuator Accessories | Pilot Solenoid 115 VAC |
| REPLACEMENT OR OBSOLETE ITEM | OBSOLETE |
| CROSS REFERENCE ITEM | PHH28ATSR08310A |
| Series | PHH |
| Operator | Actuator |
| Actuator Part Number | AP73SR5 |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI(D) | 300 psi |
| Valve CWP | 600 psi |
| Porting Style | Full |
| Port Opening Size | 2 |
| Temperature Range - Media | -20 to 370 ºF |
| Temperature Range - Ambient | -10 to 195 ºF |
| Weight | 12.55 lb |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Value Body Material | Brass |
| Valve Construction | Brass |
| Stem Seal Type | Viton® |
| Body Finish | Carbon Steel |
| Ball Material | Chrome Plated Brass |
| Seat Material | RTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | Stainless Steel |
| Body Length | 5.31 in |
| B Dimensions | 3.77 in |
| Body Inner Diameter | 1.97 in |
| D Dimensions | 2.71 in |
| E Dimensions | 7.75 in |
| F Dimensions | 7.07 in |
| G Dimensions | 3.92 in |
| H Dimensions | 5.04 in |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
