Additional information
| Valve Size | 1/2 in |
|---|---|
| Pneumatic Actuator Type | Double Acting |
| Pneumatic Actuator Accessories | Pilot Solenoid 24 VAC |
| REPLACEMENT OR OBSOLETE ITEM | REPLACEMENT |
| CROSS REFERENCE ITEM | PYHG3AUD01A3 |
| Series | PYHG |
| Operator | Actuator |
| Actuator Type | HP032DA |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI(D) | 300 psi |
| Valve CWP | 400 psi |
| Porting Style | L Port |
| Port Opening Size | 2-Jan |
| Temperature Range - Ambient | -4 to 176 ºF |
| Body Style | 3-Way |
| Number of Ports | 3 |
| Valve Body Material | Brass |
| Valve Construction | Brass |
| Stem Seal Type | Viton |
| Body Finish | Brass |
| Ball Material | Nickel Plated Brass |
| Seat Material | PTFE/Viton |
| Seal Type | PTFE/Viton |
| Stem Material | Nickel Plated Brass |
| A Dimensions | 2.87 in |
| C Dimensions | 0.43 in |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Valve Features | 100 WSP Sized for 300 psid media., Standard PortBrass Body with Ni-Chrome Plated BallPTFE Seats, Viton® O-Ring Stem SealBottom Loaded StemAvailable in 1/4" – 3" FNPT Ends400 PSI WOG |
| Actuator Features | -4 to 176 deg F (Low Temp and High Temp also available), 4X) to provide local and remote indication of valve position (2 SPDT switches)Life-time lubricated, high cycling, Quarter-Turn, rack and pinion |
| Temperature Range - Media | -4 to 200 °F |
