Additional information
| Valve Size | 1 1/2 in |
|---|---|
| Electric Voltage | 115 VAC |
| Series | E2C |
| Operation Type | Actuator |
| Actuator Type | DE155 |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI(D) | 300 psi |
| Valve CWP | 1000 psi |
| Porting Style | Full |
| Port Opening Size | 1 1/2 |
| Temperature Range - Media | -4 to 392 ºF |
| Temperature Range - Ambient | -40 to 150 ºF |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Valve Body Material | Carbon Steel |
| Valve Construction | Carbon Steel |
| Stem Seal Type | PTFE/Viton® |
| Body Finish | Carbon Steel |
| Ball Material | 316 Stainless Steel |
| Seat Material | RTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | 316 Stainless Steel |
| A Dimensions | 4.72 in |
| C Dimensions | 1.50 in |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Features | NPT Female Threaded Ends (ASME B1.20.1) or Socket Weld Connections (ANSI B16.11)Carbon Steel (A216-WCB) Investment Cast ConstructionRTFE Seats, PTFE/Viton® Stem SealsStainless Steel Bottom Loaded Stem and BallNEMA 4/4X Actuator |
