Additional information
| Valve Size | 4 in |
|---|---|
| Electric Voltage | 460 VAC PH3 |
| REPLACEMENT OR OBSOLETE ITEM | REPLACEMENT |
| CROSS REFERENCE ITEM | EHS2BEJE03G |
| Series | E5S |
| Operator | Actuator |
| Valve Type | Ball |
| Thread Type | #150 Flange |
| Operating PSI(D) | 285 psi |
| Valve CWP | 285 psi |
| Porting Style | Full |
| Port Opening Size | 4 |
| Temperature Range - Media | -4 to 392 ºF |
| Temperature Range - Ambient | 10 to 140 ºF |
| Body Style | 2 Piece Flange |
| Number of Ports | 2 |
| Valve Body Material | Stainless Steel |
| Valve Construction | Stainless Steel |
| Body Finish | Stainless Steel |
| Ball Material | 316 Stainless Steel |
| Stem Material | 316 Stainless Steel |
| A Dimensions | 9.02 in |
| C Dimensions | 3.86 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Actuator Type | MA20 |
| Seal Type | Seals/O-Ring: Graphite/Viton |
| Seat Material | RTFE |
| Stem Seal Type | Graphite/Viton |
