Additional information
| Valve Size | 1 1/4 |
|---|---|
| Electric Voltage | 115 VAC |
| Addl Voltage | Electric |
| Series | EHH |
| Operator | Electric Actuator |
| Actuator Type | ON/OFF |
| Actuator Part Number | DE153 |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI (D) | 300 psid |
| Valve CWP | 600 cwp |
| Porting Style | Full |
| Port Opening Size | 1.26 in |
| Temperature Range - Media | -20 to 370 ºF |
| Temperature Range - Ambient | -40 to 150ºF |
| Weight | 6.94 |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Stem Seal Type | Viton |
| Body Finish | Forged Brass |
| Seat Material | RTFE |
| Seal Type | Viton |
| Stem Material | Nickel Plated Brass |
| A Dimensions | 4.09 in |
| B Dimensions | 2.56 in |
| C Dimensions | 1.26 in |
| D Dimensions | 2.18 in |
| E Dimensions | 7.36 in |
| F Dimensions | 5.66 in |
| G Dimensions | 4.24 in |
| H Dimensions | 5.18 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Valve Body Material | Brass |
| Valve Construction | 2 Piece |
| Ball Material | Chrome Plated Brass |
