Additional information
| Valve Size | 1 1/2 in |
|---|---|
| Electric Voltage | 220 VAC (3 Phase) |
| REPLACEMENT OR OBSOLETE ITEM | OBSOLETE |
| CROSS REFERENCE ITEM | E5S27EJE07F |
| Series | EHS FL |
| Operator | Actuator |
| Actuator Type | Electric |
| Actuator Part Number | MA7F |
| Valve Type | Ball |
| Thread Type | 150 ANSI Flange |
| Operating PSI (D) | 175 psi |
| Valve CWP | 175 psi |
| Porting Style | Full |
| Port Opening Size | 1 1/2 |
| Temperature Range - Media | -15 to 300 ºF |
| Temperature Range - Ambient | 10 to 140 ºF |
| Body Style | 2 Piece |
| Number of Ports | 2 |
| Valve Body Material | Stainless Steel |
| Valve Construction | Stainless Steel |
| Stem Seal Type | PTFE/Viton® |
| Body Finish | Stainless Steel |
| Ball Material | 316 Stainless Steel |
| Seat Material | RTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | 316 Stainless Steel |
| Body Length | 6.50 in |
| B Dimensions | 1.50 in |
| C Dimensions | 5.00 in |
| D Dimensions | 2.99 in |
| E Dimensions | 7.87 in |
| G Dimensions | 10.04 in |
| H Dimensions | 5.13 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
