Additional information
| Valve Size | 2 in |
|---|---|
| Electric Voltage | 115 VAC |
| Series | EVA |
| Operator | Actuator |
| Actuator Type | Electric |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI (D) | 300 psi |
| Valve CWP | 600 psi |
| Porting Style | Full |
| Port Opening Size | 2 |
| Temperature Range - Ambient | -40 to 150 ºF |
| Voltage | 120 VAC |
| Weight | 12.38 lb |
| Body Style | 3 Piece |
| Number of Ports | 2 |
| Valve Body Material | Bronze |
| Valve Construction | Bronze |
| Stem Seal Type | PTFE/Viton® |
| Body Finish | Bronze |
| Ball Material | 316 Stainless Steel |
| Seat Material | PTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | Stainless Steel |
| Body Length | 5.39 in |
| B Dimensions | 3.00 in |
| C Dimensions | 1.97 in |
| D Dimensions | 13.04 in |
| E Dimensions | 7.87 in |
| G Dimensions | 10.04 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Actuator Part Number | MA4 actuator |
| Temperature Range - Media | -20°F to 400°F |
