Additional information
| Valve Size | 2 1/2 in |
|---|---|
| Electric Voltage | 220 VAC (3 Phase) |
| Series | EYHG |
| Operator | Actuator |
| Actuator Type | Electric |
| Actuator Part Number | MA7F |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI (D) | 300 psi |
| Valve CWP | 400 psi |
| Porting Style | Standard |
| Port Opening Size | 2 1/2 |
| Temperature Range - Media | -20 to 300 ºF |
| Temperature Range - Ambient | 10 to 140 ºF |
| Body Style | 3-Way |
| Number of Ports | 3 |
| Valve Body Material | Brass |
| Valve Construction | Brass |
| Stem Seal Type | Viton® |
| Body Finish | Brass |
| Ball Material | Ni-Chrome Plated Brass |
| Seat Material | PTFE |
| Seal Type | PTFE/Viton® |
| Stem Material | Nickel Plated Brass |
| Body Length | 6.93 in |
| B Dimensions | 4.37 in |
| C Dimensions | 1.95 in |
| D Dimensions | 3.47 in |
| E Dimensions | 2.20 in |
| F Dimensions | 3.35 in |
| G Dimensions | 13.39 in |
| H Dimensions | 13.00 in |
| J Dimensions | 7.87 in |
| K Dimensions | 10.04 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
