Additional information
| Pneumatic Actuator Type | Double Acting |
|---|---|
| Pneumatic Actuator Accessories | Pilot Solenoid 12 VDC |
| CROSS REFERENCE ITEM | PYSA5AJD05A4 |
| Operator | Actuator |
| Actuator Type | HP075DA |
| Valve Type | Ball |
| Thread Type | FNPT |
| Operating PSI(D) | 300 psi |
| Valve CWP | 1000 psi |
| Porting Style | L Port |
| Temperature Range - Ambient | -4 to 176 ºF |
| Body Style | 2 Piece |
| Number of Ports | 3 |
| Valve Body Material | Stainless Steel |
| Valve Construction | Stainless Steel |
| Stem Seal Type | Viton |
| Body Finish | Stainless Steel |
| Ball Material | 316 Stainless Steel |
| Seat Material | PTFE |
| Stem Material | 316 Stainless Steel |
| A Dimensions | 4.37 in |
| C Dimensions | 1.00 in |
| Seal Type | Viton |
| Application | Agricultural and Food Processing, Alternative Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Actuator Features | -4 to 176 deg F (Low Temp and High Temp also available), 4X) to provide local and remote indication of valve position (2 SPDT switches)Life-time lubricated, high cycling, Quarter-Turn, rack and pinion |
| Series | PYSG |
| Valve Size | 1 1/4 in |
| Port Opening Size | 0.98 |
