V3S27AJ, 1 1/2" Stainless Steel 3-Piece Bolted In-Line Valve - V3S Series

Valve Size 1 1/2 in
End Connections FNPT
Valve CWP 1000 psi
Porting Full
A - Port Diameter 1.26 in
Handle Type Locking
Series VVS
Thread Type FNPT
Valve Type Ball
Operation Type Manual
Ball Pattern Conventional, Bi-Directional
Body Style 3 Piece
Temperature Range -20 to 450 ºF
Weight 1.40 lb
Number of Ports 2
Valve Working Steam Pressure 150 psi
Ball Material 316 Stainless Steel
Seat Material RTFE
Body Material Stainless Steel
Handle Finish Vinyl Grip
Body Finish Stainless Steel
Seal Type PTFE
Stem Material 316 Stainless Steel
Handle Material Stainless Steel
Trim Material Stainless Steel
B Dimensions 2.42 in
E Dimensions 4.92 in
Application Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Effluent Lines, Degreasing, Pickling, Plating, Washdown, Demineralizers, Dewatering and Sludge Movement, Filtration Systems, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Mixing, Filling, Material Flow, Municipal Service, Natural Gas and Oil Production, Solid and Liquid Waste Control, Steel Mills, General Chemical Applications

V3S Series ball valves are designed for food and general chemical applications where maintenance is key. Three-piece 316 SS bodies and end caps are available in NPT threaded or Socket weld end connections. Valve features RTFE seats, blowout-proof stems and actuator mounting pad. ISO 5211 mounting pad makes automation easy! See our DynaMatic E3S and P3S series for actuator assemblies.

Key Benefits:

  • ISO 5211 direct mount pad provides accurate stem alignment and eliminates need for brackets.
  • 3-Piece swing-out design provides easy in-line maintenance.
  • Blowout Proof Stem Design and adjustable stem seal


  • For Manual Handle, see our V6S series.

Note:  Valve shown in image is our Carbon Steel Valve.  Actual product is 316 Stainless Steel.
