Additional information
| Valve Size | 3/4 in |
|---|---|
| End Connections | FNPT |
| Valve CWP | 1000 psi |
| Porting | Full |
| A - Port Diameter | 0.79 in |
| Handle Type | Locking |
| Series | VVS |
| Thread Type | FNPT |
| Valve Type | Ball |
| Operation Type | Manual |
| Ball Pattern | Bi-Directional, Conventional |
| Body Style | 3 Piece |
| Weight | 2.10 lb |
| Number of Ports | 2 |
| Valve Working Steam Pressure | 150 psi |
| Ball Material | 316 Stainless Steel |
| Seat Material | RTFE |
| Body Material | Stainless Steel |
| Handle Finish | Vinyl Grip |
| Body Finish | Stainless Steel |
| Seal Type | PTFE |
| Stem Material | 316 Stainless Steel |
| Handle Material | Stainless Steel |
| Trim Material | Stainless Steel |
| B Dimensions | 3.09 in |
| E Dimensions | 4.92 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
| Temperature Range | -4°F to 392°F |
