VMA1.A90P 1 1/4, Bronze 2-Piece Screwed Body Valve - VMA Series

Valve Size 1 1/4 in
Ball Material Chrome Plated Brass
Stem Material Brass
Valve CWP 600 psi
Body Inner Diameter 1.06 in
Handle Type Locking
Series VMA
Thread Type FNPT
Valve Type Ball
Operation Type Manual
Ball Pattern Straight Through
End Connections FNPT
Body Style 2 Piece
Porting Full
Temperature Range -20 to 450 ºF
Weight 2.42 lb
Number of Ports 2
Valve Working Steam Pressure 150 psi
Seat Material RTFE
Body Material Bronze
Stem Seal Type PTFE
Handle Finish Zinc Plated, Vinyl Grip
Seal Type PTFE
Handle Material Steel
Trim Material Brass
Body Length 3.50 in
E Dimensions 7.00 in
Application Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Effluent Lines, Degreasing, Pickling, Plating, Washdown, Demineralizers, Dewatering and Sludge Movement, Filtration Systems, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Mixing, Filling, Material Flow, Municipal Service, Natural Gas and Oil Production, Solid and Liquid Waste Control, Steel Mills, General Chemical Applications
VMA Series ball valves offer maximum strength, durability, and maintenance-free operation all in one package! Industrial two-piece bronze valves are precision machined and designed to outlast lightweight competitors.

Key Benefits:
  • Corrosion-Resistant Bronze Body Construction
  • Reinforced PTFE Seats and Seals
  • Blowout-Proof Stem Design with Adjustable Packing
  • Unique adjustable Stem Packing
Options:
  • Stainless Steel Ball and Stem (OA)
  • Latching Lockout Handle Kit (OP)
