Additional information
| Valve Size | 1/4 in |
|---|---|
| Ball Material | 316 Stainless Steel |
| Seat Material | RTFE |
| Valve CWP | 2000 psi |
| A - Port Diameter | 0.40 in |
| Handle Type | Lever |
| Series | VME1 |
| Thread Type | FNPT |
| Valve Type | Ball |
| Operation Type | Handle |
| Ball Pattern | Bi-Directional, Conventional |
| End Connections | FNPT |
| Body Style | 2 Piece |
| Porting | Full |
| Temperature Range | -20 to 425 ºF |
| Weight | 0.60 lb |
| Number of Ports | 2 |
| Body Material | Carbon Steel |
| Stem Seal Type | RTFE |
| Handle Finish | Vinyl Grip, Zinc Plated |
| Body Finish | Zinc Phos Coated |
| Seal Type | RTFE |
| Stem Material | Nickel Plated Steel |
| Handle Material | Steel |
| Trim Material | Carbon Steel |
| B Dimensions | 2.00 in |
| D Dimensions | 3.78 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
