VVA2.AMAP 1/2, Bronze 3-Piece Bolted In-Line Valve – VVA Series

Additional information

Valve Size

1/2 in

Thread Type

FNPT

Valve CWP

600 psi

A - Port Diameter

0.59 in

Handle Type

Locking

Series

VVA

Valve Type

Ball

Operation Type

Manual

Ball Pattern

Straight Through

End Connections

FNPT

Body Style

3 Piece

Porting

Full

Weight

1.32 lb

Number of Ports

2

Ball Material

316 Stainless Steel

Seat Material

PTFE

Body Material

Bronze

Handle Finish

Vinyl Grip

Seal Type

PTFE/Viton®

Stem Material

316 Stainless Steel

Handle Material

Stainless Steel

Trim Material

Stainless Steel

B Dimensions

2.68 in

E Dimensions

4.33 in

Application

Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown

Temperature Range

-20°F to 400°F

Description

VVA Series ball valves are designed for general media service applications where simple and fast installation and maintenance is key! These three-piece bolted in-line valves feature corrosion-resistant Bronze Body and stainless steel ball and stem for maximum durability. Avail in Female NPT threads with latch lock handles standard. Valves feature a unique adjustable stem packing to allow adjustment without handle or actuator removal. ISO 5211 mounting pad makes automation easy! See our DynaMatic EVA and PVA series for assemblies.

Key Benefits:

  • Heavy Duty Construction
  • Simple, Fast Installation and Maintenance
  • Unique adjustable Stem Packing
  • 316 SS Ball and Stem
  • Latch-Lock handle standard.
