Additional information
| Valve Size | 3/8 in |
|---|---|
| Thread Type | FNPT |
| Valve CWP | 400 psi |
| Port Diameter | 0.43 in |
| Temperature Range | -20 to 450 ºF |
| Handle Type | Lever |
| Series | VYH |
| Valve Type | Ball |
| Operation Type | Manual |
| Ball Pattern | L |
| End Connections | FNPT |
| Body Style | 3-Way |
| Porting | Standard |
| Weight | 1.16 lb |
| Number of Ports | 3 |
| Ball Material | Ni-Chrome Plated Brass |
| Seat Material | PTFE |
| Body Material | Brass |
| Handle Finish | Vinyl Grip |
| Seal Type | PTFE/Viton® |
| Stem Material | Nickel Plated Brass |
| Handle Material | Steel |
| Trim Material | Brass |
| B Dimensions | 2.64 in |
| G Dimensions | 4.72 in |
| Application | Agricultural and Food Processing, Altertive Energy and Fuel Production, Bulk Product Movement, Chemical Processing, Compressed Air Services, Condensate Removal, Coolants, Degreasing, Demineralizers, Dewatering and Sludge Movement, Effluent Lines, Filling, Filtration Systems, General Chemical Applications, Hydraulic/Pneumatic Systems and Lifts, Ink Spraying and Cleaning, Line Purge, Machine Cooling, Material Flow, Mixing, Municipal Service, Natural Gas and Oil Production, Pickling, Plating, Solid and Liquid Waste Control, Steel Mills, Washdown |
